Industrial Steam Jacketed Cooking Pot Electric Electromagnetic And Gas-Fired Mixing Jacketed Kettle For Nuts Jams Soups Vegetables And Meats

*Type Of Machine*	Jacketed Kettle
*For Food Type*	Sauces, Stir-Fries, Nuts, Fillings Etc.
*Automatic*	Automatic
*Voltage*	220V/380V
*Customized*	Customized
*Material*	304 Stainless Steel
*Origin*	Shandong China
*Production Capacity*	100-1000kg/Time
*Heating Method*	Electricity/Gas/Steam Heating

Descriptions

Industrial Steam Jacketed Cooking Pot Electric Electromagnetic And Gas-Fired Mixing Jacketed Kettle For Nuts Jams Soups Vegetables And Meats Specification

Steam-Jacked Kettle
Model	Diameter Mm	Degree Of Depth Mm	Inner And Outer Wall Thickness	Long	Wide	Tall	Power Of Agitator
100L	700	500	Inner 3MM, Outer 3MM	1280	800	600	0.75KW
200L	800	550	Inner 3MM, Outer 3MM	1380	900	650	1.1KW
300L	900	600	Inner 3MM, Outer 3MM	1480	1000	700	1.5KW
400L	1000	650	Inner 3MM, Outer 3MM	1580	1100	750	1.5KW
500L	1100	700	Inner 4MM, Outer 3MM	1680	1200	800	2.2KW
600L	1200	750	Inner 4MM, Outer 3MM	1780	1300	850	2.2KW
800L	1300	800	Inner 4MM, Outer 4MM	1880	1400	900	3KW
1000L	1400	850	Inner 4MM, Outer 4MM	1980	1500	950	3KW

Electrically Heated Jacketed Pot
Model	Diameter Mm	Degree Of Depth Mm	Inner And Outer Wall Thickness	Power	Long	Wide	Tall	Power Of Agitator
100L	700	500	Inner 3MM, Outer 3MM	18KW	1080	600	500	0.75KW
200L	800	550	Inner 3MM, Outer 3MM	18KW	1130	650	525	1.1KW
300L	900	600	Inner 3MM, Outer 3MM	24KW	1180	700	550	1.5KW
400L	1000	650	Inner 3MM, Outer 3MM	27KW	1230	750	575	1.5KW
500L	1100	700	Inner 3MM, Outer 3MM	36KW	1280	800	600	2.2KW
600L	1200	750	Inner 3MM, Outer 3MM	36KW	1330	850	625	2.2KW
800L	1300	800	Inner 3MM, Outer 3MM	48KW	1380	900	650	3KW
1000L	1400	850	Inner 3MM, Outer 3MM	48KW	1430	950	675	3KW

Gas Jacketed Pot
Model	Diameter Mm	Degree Of Depth Mm	Inner And Outer Wall Thickness	Long	Wide	Tall	Gas Volume	Power Of Agitator
100L	700	500	Inner 4MM, Outer 3MM	1330	850	600	6KG	0.75KW
200L	800	550	Inner 4MM, Outer 3MM	1430	950	650	6KG	1.1KW
300L	900	600	Inner 4MM, Outer 3MM	1530	1050	700	6KG	1.5KW
400L	1000	650	Inner 4MM, Outer 3MM	1630	1150	750	6KG	1.5KW
500L	1100	700	Inner 4MM, Outer 3MM	1730	1250	800	6KG	2.2KW
600L	1200	750	Inner 4MM, Outer 3MM	1830	1350	850	6KG	2.2KW
800L	1300	800	Inner 5MM, Outer 3MM	1930	1450	900	6KG	3KW
1000L	1400	850	Inner 5MM, Outer 3Mm	2030	1550	950	6KG	3KW
